ENCAP Supercapacitors
Efficient Power for Demanding Environments
Designed for data centers, grid stabilization, and industrial operations, ENCAP offers fast charging, long lifespan, and sustainable materials. Optimize energy management while cutting costs and ensuring reliable performance.
Main Charactristics
DC Energy | 7.1kWh |
Voltage Range | 43.2Vdc to 60.8Vdc |
DC Voltage (Nominal) | 48Vdc |
Internal Resistance | < 4 mili Ohms |
Maximum Continuous Charge/Discharge Current | 150A (~1C) |
Charging/Discharging Method | CC/CP/VP |
Operating Temperature Range | -30oC~ +70oC |
Operating Humidity | Non-Condensing |
Technology | Encapsulated Cell |
Cells Projected Cycle Life | 500,000 cycles |
Cells Projected Calendar Life | 25 years |
Mechanical Specifications
Terminal Type | 300A Terminal Post |
Module Casing Material | GI Powdered |
Weight (kg) | 43 |
Dimensions1 (W x H x D) mm | 482 x 134 x 568 |
7.1KWH-48V Module
The ENCAP 7.1KWH-48V module offers reliable energy storage in a compact form, with a nominal voltage of 48Vdc.
100% DOD
> 95% RTE (Round Trip Efficiency)
250 Wh/kg at the cell level and 110 Wh/kg at the module level.
Over 500,000 charge cycles for extended use.
Incorporates Encapsulated Hybrid Graphene, Solid State, and Tantalum Capacitors.
100% recyclable and biodegradable materials.
Operates between 43.2V to 60.8V, supporting up to 1000V in series connection.
Capable of charging and discharging at high rates, with minimal transmission losses.
Includes thermal runaway prevention, short-circuit protection, and over/under-voltage safeguards.
Equipped with Wi-Fi, CANBUS, and Bluetooth communication, along with an OLED display and EN Connect AI platform for monitoring and control.
.png)
UNMATCHED
SAFETY
Includes robust thermal management and fire suppression systems, ensuring safe operation under all conditions.
SUPERFAST CHARGING &
DISCHARGING
ENCAP modules support rapid charging and can be designed for fast discharge, ensuring quick energy availability when needed.
HIGH ENERGY
DENSITY & EFFICIENCY
Compact design offers superior energy storage, with high round-trip efficiency, minimizing energy loss.
LONG LIFESPAN
WITH NO DEGRADATION
With no chemical reactions, ENCAP modules offer over 500,000 life cycles and maintain performance without degradation over 10 years.
WIDE OPERATING
TEMPERATURE RANGE
Operates efficiently between -30°C to +65°C, making it suitable for diverse environments.
ENVIRONMENTAL
SUSTAINABILITY
Made from 100% recyclable and biodegradable materials, ENCAP is an eco-friendly alternative to traditional batteries.
100% DEPTH OF
DISCHARGE (DOD)
Allows full utilization of stored energy, maximizing system efficiency.
REMOTE MONITORING
& MANAGEMENT
ntegrated with ENServer for intelligent energy management and offers remote monitoring through an app or OLED display, optimizing energy flow and reducing operational costs.
SYMATX
Revolutionize Your Energy Storage
Have a project in mind? Let’s discuss how Symatx can power your vision.
Modular Precision: Integrating ENCAP with ENRACK for Scalable Power Solutions
ENRACK’s advanced modular design seamlessly integrates with ENCAP, enabling scalable, high-density energy storage.
This robust system optimizes performance across demanding applications, ensuring precise energy management, enhanced safety, and superior efficiency, making it ideal for data centers, industrial operations, and renewable energy systems.
ENRACK houses ENCAP modules, providing a unified and scalable energy storage solution.
Modular design supports flexible configurations, scaling from kilowatt-hour modules to large megawatt-hour systems.
Optimized for high energy density and round-trip efficiency, ensuring reliable performance.
Includes robust safety features such as thermal management, fire suppression, and advanced monitoring systems.
Ideal for demanding environments like data centers, industrial applications, and renewable energy systems.
Main Charactristics
DC Energy | 10kWh |
Voltage Range | 43.2Vdc to 60.8Vdc |
DC Voltage (Nominal) | 48Vdc |
Module Projected Shelf Life | 10 years |
Cells Projected Calendar Life | 25 years |
Internal Resistance | < 4 mili Ohms
|
Cells Projected Cycle Life | 500,000 cycles |
Operating Temperature Range | -30C~ +70C |
Technology | Encapsulated Cell |
Operating Humidity | Non-Condensing |
Charging/Discharging Method | CC/CP/VP |
Maximum Continuous Charge/Discharge Current | 200A (~1C) / 300A (~1.5C) |
Mechanical Specifications
Weight (kg) | 120 |
Dimensions1 (W x H x D) mm | 433 x 335 x 650 |
Terminal Type | 300A Terminal Post |
Module Casing Material | GI Powdered |
10KWH-48V Module
The ENCAP 10KWH-48V module is tailored for industrial and commercial energy storage, offering reliability and efficiency with advanced encapsulated hybrid graphene technology.
It seamlessly integrates into various systems, providing a sustainable energy storage solution that supports operational cost reduction and improved energy management.
100% DOD
> 95% RTE (Round Trip Efficiency)
250 Wh/kg at the cell level and 110 Wh/kg at the module level.
Over 500,000 charge cycles for extended use.
Incorporates Encapsulated Hybrid Graphene, Solid State, and Tantalum Capacitors.
100% recyclable and biodegradable materials.
Operates between 43.2V to 60.8V, supporting up to 1000V in series connection.
Capable of charging and discharging at high rates, with minimal transmission losses.
Wide Operating Temperature Range
Deployable in Various Environments including High Altitudes
No Thermal Runaway Risk
Feature-rich Online Monitoring via App or OLED Display
Automatic Firmware Updates
Warning Alarms
Main Charactristics
DC Energy | 10kWh |
Voltage Range | 43.2Vdc to 60.8Vdc |
DC Voltage (Nominal) | 48Vdc |
Module Projected Shelf Life | 10 years |
Cells Projected Calendar Life | 25 years |
Internal Resistance | < 4 mili Ohms
|
Cells Projected Cycle Life | 500,000 cycles |
Operating Temperature Range | -30C~ +70C |
Technology | Encapsulated Cell |
Operating Humidity | Non-Condensing |
Charging/Discharging Method | CC/CP/VP |
Maximum Continuous Charge/Discharge Current | 200A (~1C) / 300A (~1.5C) |
Mechanical Specifications
Weight (kg) | 120 |
Dimensions1 (W x H x D) mm | 433 x 335 x 650 |
Terminal Type | 300A Terminal Post |
Module Casing Material | GI Powdered |
10KWH-48V Series Module
The ENCAP 10kWh-48V (Series Connections) is specifically designed for high-voltage applications requiring series connections. It combines advanced encapsulated hybrid graphene technology with robust performance, ensuring reliable and scalable energy storage.
Ideal for large-scale industrial systems, this module supports extensive voltage ranges and provides a sustainable solution with minimal operational costs.
100% DOD
> 95% RTE (Round Trip Efficiency)
250 Wh/kg at the cell level and 110 Wh/kg at the module level.
Over 500,000 charge cycles for extended use.
Incorporates Encapsulated Hybrid Graphene, Solid State, and Tantalum Capacitors.
100% recyclable and biodegradable materials.
Operates between 43.2V to 60.8V, supporting up to 1000V in series connection.
Capable of charging and discharging at high rates, with minimal transmission losses.
Wide Operating Temperature Range
Deployable in Various Environments including High Altitudes
No Thermal Runaway Risk
Feature-rich Online Monitoring via App or OLED Display
Automatic Firmware Updates
Warning Alarms
